Polygon Trid ZZ
🔥 Get Ready for Summer SALE – ends in
Polygon Trid ZZ
Specifications
Frameset AL6 SLOPE STYLE, 100MM TRAVEL, POSTMOUNT 160MM
Fork ROCKSHOX PIKE DJ, TRAVEL 100MM, TAPERED STEERER
Rear Shock ROCKSHOX MONARCH R, 7.5”X2.00”(190X51MM), M8X22MM
Drivetrain
Shifter SRAM GX-DH, 7-SPEED TRIGGER
Rear Derailleur SRAM RD-GX-1DH-A3 DA
Crank ALLOY 2-PIECE CRANKSET 32T
BB SAMOX INTEGRATED BB BSA
Cassette SRAM PG-720 11-25T
Chain KMC X11
Cockpit
Saddle POLYGON PIVOTAL SADDLE
Handlestem ALLOY E:40MM R:0DEG BB:31.8MM
Seatpost ALLOY, PIVOTAL, 30.9X200MM
Heaadset ZS 44/28.6 | ZS 56/40
Handlebar ALLOY W:750MM R:38.1MM BB:3.18MM
Wheel & Tire
Wheel Set ALLOY DOUBLE WALL RIM W/ THRU AXLE HUBS
Tire VEE TIRES XCV (TWO SIX DJ) 26"x2.25"
Wheel Size 26"
Rim 559x24C 32H FOR TYRE 559-44/76 W/ EYELET
Brake
Brake Lever SHIMANO MT501
Brake Caliper SHIMANO MT500 HYDRAULIC DISC BRAKE
Rotor SHIMANO SM-RT56
Geometry & Size
| All Size | |
|---|---|
| Height (cm) | 172-185 |
| Seat Tube Length (A) | 330 |
| Seat Tube Angle (B) | 70 |
| Effective Seat Tube Angle (C) | 75 |
| Head Tube Length (D) | 120 |
| Head Tube Angle (E) | 69 |
| Effective Top Tube (F) | 575 |
| Bb Height (G) | 331 |
| Bb Offset (H) | 8 |
| Chainstay Length (I) | 400 |
| Wheelbase (J) | 1079.1 |
| Frame Reach (K) | 425 |
| Frame Stack (L) | 558.5 |
| Standover Height (M) | 649 |
