Polygon Xtrada 5
🔥 Get Ready for Summer SALE – ends in
ADVENTURE STARTS HERE
Riding the Xtrada feels like running with a wolf,” they said. True to its cross-country DNA, the Xtrada is born to run the trail with you—impeccably versatile, effortlessly fast, and obsessively comfortable. Built with speed-focused, stable geometry and tough, trail-ready components, it’s the perfect companion for local singletrack laps or all-day mountain adventures.
Features
Effortless shifting with a 1x drivetrain, paired with UDH compatibility for next-generation drivetrains
A suspension fork designed to take the edge off rough terrain and keep your ride composed
Dropper post for uninterrupted focus, up or down *Xtrada 7 and 6 series
Specifications
*Specifications, colors, and product availability are subject to change without prior notice.
Frameset
ALX XC 29"
Fork
SUNTOUR XCM 32 120MM TRAVEL BOOST THRU AXLE
Rear Shock
-
Frame Color
RED BLACK
Decal Color
GOLD BLACK
Drivetrain
Shifter
SHIMANO CUES SL-U6000 1x10-SPEED TRIGGER
Crank
PROWHEEL RMZ-MD25S-TT 32T 170mm
Cassette
SHIMANO CS-LG300 10-SPEED 11-48T
Rear Derailleur
SHIMANO CUES RD-U6000 DIRECT ATTACH
BB
PROWHEEL 2 PIECE CRANKSET BSA THREADED
Chain
KMC X-GLIDE
Pedal
ONE PIECE PP BODY
Cockpit
Saddle
LINC VOID SADDLE, STEEL ø 7mm
Seatpost
POLYGON SPORT SEATPOST, DXL: 30.9 x 350mm, OFFSET: 0mm, SEAT CLAMP: 34.9mm QR TYPE
Handlebar
POLYGON SPORT, W: 760mm, BB: 31.8mm, R/D: 20mm, B: 9degree
Handlestem
POLYGON SPORT, EXT: 40mm, BB: 31.8mm, R/D: 7degree
Headset
ZERO STACK W/ SEALED BEARING, ZS 44/28.6 | ZS 56/40
Wheel & Tire
Wheel Set
ALLOY WHEELS
Tire
WTB TRAIL BOSS 29"X2.25"
Rim
ALLOY DOUBLE WALL H: 19mm W: 23mm 32H FOR TYRE 622-68
Hub
F: ALLOY HUB THRU AXLE 15x110mm 32H CENTERLOCK / R: ALLOY HUB THRU AXLE 12x148mm 32H CENTERLOCK
Spokes
F: 14G STAINLESS NDS: 294mm DS: 292mm 12MM NIPPLE BRASS / R: 14G STAINLESS NDS: 292mm DS: 290 12MM NIPPLE BRASS
Brake
Brake Lever
SHIMANO BL-MT200
Brake Caliper
SHIMANO MT200 HYDRAULIC DISC BRAKE
Rotor
SHIMANO SM-RT10 F: 180mm R: 160mm CENTERLOCK
Geometry & Size
| S | M | L | XL | |
|---|---|---|---|---|
| Height (cm) | 152-165 | 162-175 | 172-185 | 182-195 |
| Seat Tube Length (A) | 390 | 430 | 450 | 470 |
| Seat Tube Angle (B) | 73 | 73 | 73 | 73 |
| Effective Seat Tube Angle (C) | 74 | 74 | 74 | 74 |
| Head Tube Length (D) | 90 | 100 | 110 | 120 |
| Head Tube Angle (E) | 67 | 67 | 67 | 67 |
| Effective Top Tube (F) | 586 | 609 | 632 | 655 |
| Bb Height (G) | 313 | 313 | 313 | 313 |
| Bb Offset (H) | 60 | 60 | 60 | 60 |
| Chainstay Length (I) | 432 | 432 | 437 | 437 |
| Wheelbase (J) | 1121 | 1145 | 1174 | 1198 |
| Frame Reach (K) | 410 | 430 | 450 | 470 |
| Frame Stack (L) | 620 | 629 | 638 | 647 |
| Standover Height (M) | 725 | 756 | 772 | 788 |
