The Cargo V3 everybody! The same fast and light Omnium as you know it, now with adjustable rocker dropouts! With the big comfy tires and trusty thru axles of the WiFi, now combined with the new super functional dropouts, we once again we feel we’ve created the ultimate cargo bike where versatility is at the top of the list.
The adjustable rocker dropouts allow you to run a variety of drivetrain options (sorry not simultaneously), ranging from external gears with a derailleur to internal gears and belt drive! Heck you can even run it fixed if you’re that type of nut! The swappable inserts allow you to chose between thru axle and quick release depending on your rear hub spacing and gear component choice. Maybe even carry a spare set to easily replace a broken gear hanger if need be.
The Cargo is an incredibly versatile, lightweight and fast cargo bike that can handle heavy loads and big objects with ease.The best part is, it rides like a normal bike when unloaded, due to its clever construction and familiar geometry.
The Cargo is also the model with the longest wheelbase, which calls for very stable handling. The wheelbase also allows for great stability when loading the rack on your own, as the weight is positioned in the middle of the front wheel and the kickstand.
Need to pick up your new dream sofa? Easy. Bringing your kid to the daycare before work? No problem! Bring a computer for work or a change of clothes for the gym in a waterproof duffle and you‘re good to go, rain or shine, all year long.
Frame Specifications
| Frame material | Double-Butted Chromoly Steel Frame |
| 5 Sizes | XS, S, M, L, XL |
| Standard Rack Weight | 1320g +/- |
| Rack dimensions | 83cm x 50cm |
| Seat post diameter | 31.6 mm |
| Seat post clamp size | 34.0 mm |
| Rear Wheel | TA Insert: 622, 12 x 142mm spacing, disc only QR Insert: 622, 10 x 135mm spacing, disc only |
| Front Wheel | 406, 15 x 100 mm spacing, disc only |
| Tyre clearance, front | 55mm with mudguards |
| Tyre clearance, rear | 55mm with mudguards |
| Thru Axle Rear | 12×142, 172mm long, 19mm thread length, 1.75mm pitch |
| Thru Axle Front | 15×100, 125mm long, 17mm thread length, 1.5mm pitch |
| Fork headset | 1 1/8″ Threaded Integrated with locking cap |
| Steerer headset | 1 1/8″ Ahead |
| Bottom Bracket | BSA 68mm |
| Q-Factor/Stance | 145mm |
| Gears | For 1x rear derailleur gear system |
| Standard Rack Weight | 1320g +/- |
| Rack dimensions | 83cm x 50cm |
| Rack bolt size | M15 x 15mm |
| Weight | Complete Medium bike weighs 20kg |
| Maximum loading weight on front rack | 85 kg |
| Maximum total loading weight incl. rider | 175 kg |
| Framekit includes | – Frame – Fork – Headsets (front and rear) – Steering rod – Steerer tube – Seat clamp – Rack – Thru axles front – Comes with a choice of qr dropouts ore 12mm thru axle dropouts and thru axle The fork always comes with 15×100 Thru Axle regardless of the choice on insert. Does NOT include spacers for headset or kickstand |
