Marin Alpine Trail XR - 2026
Regular price
€5.99900
Unit price
/
Unavailable
Price includes VAT. Shipping calculated at checkout.
Not available in Rotterdam store
Not available in warehouse
Not available in Rotterdam store
Not available in warehouse
Not available in Rotterdam store
Not available in warehouse
Not available in Rotterdam store
Not available in warehouse
Not available in Rotterdam store
Available in warehouse
Not available in Rotterdam store
Not available in warehouse
Maximum enduro, zero compromises. Alpine Trail XR is your fantasy rig – slap turns, eat bumps and smash the rough until the mountain runs out. Its Series 4 Aluminum frame has geometry adjustment, a 160mm travel MultiTrac LT suspension platform and integrated downtube storage. Mixed wheel or full 29in compatible, UDH and ride-hushing chain slap protection. It’s unapologetically the best. RockShox Zeb Ultimate fork and Vivid Air Ultimate rear shock, Shimano Di2 wireless drivetrain and SRAM Maven Silver four-piston brakes – absolute fire.
Charge hard. Send big. Drift deep. Repeat.
Specification
| Brake, Front | SRAM Maven Silver, 4-Piston Hydraulic Disc, HSC 200mm RotorTRP Slate EVO, 4-Piston Hydraulic Disc , Resin Pads, 203mm Rotor |
| Brake, Rear | SRAM Maven Silver, 4-Piston Hydraulic Disc, HSC 200mm Rotor |
| Brake Levers | SRAM Maven Silver |
| Cassette | Shimano, Deore M6100 12-Speed, 10-51T |
| Chain | KMC X-12 Silver and Black |
| Crankset | RaceFace Affect, 32T, 55mm CL, 165mm |
| Frame | Series 4 6061 Aluminum, 29” Wheels, 160mm Travel MultiTrac LT Suspension Platform, Integrated Downtube Storage, Adjustable Headset & CS Length/BB Height, Full Internal Cable Routing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru- Axle, 73mm Threaded BB w/ ISCG05 Tabs |
| Grip | Marin Grizzly Lock-On |
| Handlebar | PNW Range Handlebar, 38mm Rise, 38mm Clamp, 800mm Width, 5 Degree Up, 10 Degree Back |
| Headset | FSA Custom Headset, Adjustable HTA Design |
| Hub, Front | DT Swiss 370 Classic, 110x15mm, 6-Bolt Disc, 32H |
| Hub, Rear | DT Swiss 370 Classic, 148x12mm, 6-Bolt Disc, Mircro Spline Driver, 32H |
| Rear Suspension | RockShox Vivid Air Ultimate, 205x65, 30xM8 Lower Hardware, Custom Tune |
| Rims | DT Swiss M502, 29mm Inner, 32H |
| Saddle | Marin Speed Concept |
| Seatpost | PNW Loam Post with Range Lever, Size S=150, M=170mm Travel, Size L-XL 200mm Travel, 34.9mm |
| Shift Lever | Shimano Deore Di2, 12-Speed |
| Stem | All New Marin CNC, 35mm Length, 35mm Bar Bore |
| Tires | Front: Schwalbe Magic Mary, Trail, Ultra Soft, Radial, 29x2.5" Rear: Schwalbe Albert, Trail, Soft, Radial, 27.5x2.5" |
| Derailleur, Rear | Shimano Deore Di2, 12-Speed, SGS |
| Front Suspension | RockShox Zeb Ultimate, 170mm Travel, 29", 110x15mm Maxle Stealth, 44mm Offset |
Geometry
Specifications, pricing, and availability are subject to change without notice.
